fast response.
Operating weight ( kg ) : 7700
Bucket capacity ( m³ ) : 0.33
Rated power ( kW ) : 42.4
* Widely used in municipal, transportation, gardening, farmland renovation, oil pipeline construction and other engineering projects.
* Customized Kubota turbocharged engine, fast engine response, low noise, low energy consumption.
* Best maneuverability in the industry for its tonnage, soft operation, smooth movement, good coordination of compound movement.
* In line with the principle of making crafts, new color matching paint, high comfort air conditioning, optimizing the whole vehicle pipeline as well as sheet metal details, showing exquisite workmanship.
| Item contents | Parameters | |
| L1 Maximum digging reach | mm | 6260 |
| L2 Maximum digging reach at GRP | mm | 6070 |
| L3 Maximum digging height | mm | 7085 |
| L4 Maximum unloading height | mm | 5160 |
| L5 Minimum unloading height | mm | 2476 |
| L6 8 ft. level floor digging depth | mm | 3628 |
| Item contents | Unit | Parameters |
| Operating weight | kg | 7700 |
| Engine | ||
| Engine brand/model | ||
| Rated power/rpm | kW/rpm | 42.4/2000 |
| Direct injection | ||
| 4-stroke | ||
| Water-cooled | ||
| Turbocharged | ||
| Stroke | mm | 110 |
| Cylinder bore | mm | 87 |
| Number of cylinders | ||
| Maximum torque/rpm | N·m/rpm | |
| Displacement | 2.615 | |
| Main performance | ||
| Travel speed (high/low) | km/ | |
| Swing speed | hr/ | |
| Maximum swing torque | mink | |
| Gradeability | N·m | |
| Ground specific pressure | - | |
| Bucket digging force (ISO) | kPa | |
| Arm digging force (ISO) | kN | |
| Maximum traction force | kN | |
| Travel speed (high/low) | kN | |
| Swing speed | km/ | |
| Maximum swing torque | hr/ | |
| Track | ||
| Standard track shoes width | mm | 450 |
| Number of track shoes (per side) | - | 39 |
| Number of track roller (per side) | - | 5 |
| Number of track carrier roller (per side) | - | 1 |
| Standard | ||
| Length of boom | mm | 3720 |
| Length of arm | mm | 1622 |
| Bucket capacity | m³ | 0.33 |
