Operating weight ( kg ) : 6000
Bucket capacity ( m³ ) : 0.24
Rated power ( kW ) : 35.0
* Widely used in hydro power, transportation, municipal, garden, farmland transformation, oil pipeline construction and other engineering projects.
* Electronically controlled main pump, flow matching is more accurate, with E/P/B three intelligent modes, easy to cope with various working conditions.
* High comfort, car NVH optimization technology, cab noise reduction technology industry leading, wraparound sunshade, automatic heating and cooling air conditioning, standard fresh air system.
* Newly upgraded main pump, pressure distribution is more uniform, compound operation is more smooth.
| Working range | ||
| L1 Maximum digging reach | mm | 6130 |
| L2 Maximum digging reach at GRP | mm | 5990 |
| L3 Maximum digging height | mm | 5600 |
| L4 Maximum unloading height | mm | 3885 |
| L5 Minimum unloading height | mm | 1400 |
| L6 8 ft. level floor digging depth | mm | 3430 |
| L7 Maximum vertical digging depth | mm | 2680 |
| L8 Maximum digging depth | mm | 3830 |
| L9 Minimum swing radius | mm | 2520 |
| L10 Maximum lifting height of dozer blade | mm | 390 |
| L11 Max. cutting depth of dozer blade | mm | 560 |
| Item contents | Unit | Parameters |
| Operating weight | kg | 6000 |
| Engine | ||
| Engine brand/model | ||
| Rated power/rpm | kW/rpm | 35.0/2200 |
| Direct injection | ||
| √ | ||
| 4-stroke | ||
| √ | ||
| Water-cooled | ||
| √ | ||
| Stroke | mm | 110 |
| Cylinder bore | mm | 87 |
| Number of cylinders | 4 | |
| Item contents | Unit | Parameters |
| Dimensions | ||
| A Overall height | mm | 2780 |
| B Overall length | mm | 6010 |
| C Overall width | mm | 2000 |
| D Upper structure width | mm | 1880 |
| E Chassis width | mm | 2000 |
| F Track length | mm | 2535 |
| G Track height | mm | 606 |
| H Standard track shoe width | mm | 400 |
| I Track wheelbase | mm | 1990 |
| J Track gauge | mm | 1600 |
| K Counterweight ground clearance | mm | 700 |
| L Minimum ground clearance | mm | 380 |
